簡介:


瑞士徕卡測量系統發布萊卡Cyclone 7.0軟件。新版本的軟件允許HDS用戶在測繪和制圖工程中利用激光掃描技術來生產正射影像和工程放樣。從而豐富了激光掃描系通的工程適用性，同時也降低了各種測量和制圖工程的費用。
Leica Cyclone 軟件是三維激光掃描領域內的主流軟件系統，該軟件是HDS掃描儀的配套軟件。用戶使用該軟件可以高效率地控制徕卡測量系統的多種HDS掃描儀。使用該軟件用戶可在工程測量、制圖、及各種改建工程中處理海量點雲數據。
Leica Cyclone 三維數據處理軟件的主要特點
Cyclone-SCAN
Cyclone-REGISTER
Cyclone-MODEL
Cyclone-SURVEY
Cyclone CloudWorx
輸出二維或三維圖，線畫圖，點雲圖，三維模型，ASCII坐標數據等
可控制LEICA掃描儀完成點雲數據采集
自動掃描測量標靶
設置照相機曝光和分辨率
數據采集批處理功能
依據標靶或/和點雲實現點雲拼接
數據分塊處理和管理功能
海量數據管理（可支持10億點以上的數據管理）
根據點雲自動生成平面、曲面、圓柱、彎管、法蘭…
實現三維管道設計
自動構網和生成等高線
依據切片厚度生成點雲切面
用CloudWorx模塊可在AutoCAD或MicroStation中處理點雲數據
可以輸出DXF,PTX,PTS,TXT等多種數據格式
新的正射影像功能
以前的Cyclone軟件的MODEL模塊具有材質貼圖功能，用戶可以用外部數碼相機拍攝的照片來渲染點雲。現在，該項功能得到進一步的擴充，在渲染點雲的同時用戶可以輸出正射影像。這樣一來，CAD用戶可以在糾正後的影像上精確跟蹤得到高精度的二維線畫圖。攝影測量系統中的漫長而復雜的工作流程，現在無縫地整合到了Cyclone強大的三維點雲系統之中。細節豐富的古建築正立面圖 、工廠改建工程中復雜的機器圖形，以及傳統航空攝影測量得到的地形圖都可以在Cyclone中結合點雲來獲得。


新的放樣功能
Cyclone SCAN5.8是市場上專為激光掃描儀提供放樣功能的軟件模塊。截止目前，激光掃描儀僅應用於各種測繪制圖工程中，並未在工程放樣中得到應用。現在，在新版本的支持下，具有雙軸補償器的HDS掃描儀將可以應用於簡單的工程放樣。
使用者先將放樣點的坐標上傳到控制掃描儀的筆記本電腦中，然後掃描位於對中桿上的標靶。此時，Cyclone SCAN 5.8會顯示相關的放樣信息——據此信息，作業人員按適當的方向和距離挪動對中桿，直到最終放樣出該點。該工具接收標准的測量點號記錄，可以依次放樣出多個點位。
這一新增工具的優勢在於，可以將三維激光掃描儀應用於制圖和放樣同步進行的工程。在放樣少量點的測站上，掃描儀可以替代全站儀或GNSS/GPS進行放樣，所以，該功能減少了工程項目對全站儀或GNSS/GPS的需求。
就放樣的工作效率而言，掃描儀+標靶並不及全站儀+稜鏡 或GNSS/GPS的工作效率。因此該項功能並非要取代全站儀或GPS來應用於大量點的放樣工程。但是，當僅需放樣少量點或手邊沒有其他儀器時，它卻不失為一種方便、省時的工具。
擴展了軟件的協同工作的功能
為了支持HDS激光掃描儀硬件和軟件產品日益廣泛的應用，Cyclone 5.8擴展了系統之間的協同工作能力。首先，廣大面向AutoCAD應用的徕卡 CloudWorx用戶現在可以通過免費的Cyclone VIEWER模塊處理其它儀器（如航空雷達、非徕卡測量系統的掃描儀）的ASCII, PTS 和 PTX等格式的數據。在Cyclone 5.8之前的版本，用戶需要購買Cyclone 軟件中的相關軟件來進行數據轉換。其次，Cyclone 5.8目前可以通過一種新的PTZ數據格式，將HDS的數據導出到LFM軟件中。
正射影像圖生成、放樣以及兼容性擴展了徕卡Cyclone5.8軟件的更多拓展空間
需要說明的是，在該次軟件發布之前，徕卡測量系統已經發布了Cyclone5.8的一些新功能，包括：HDS6000掃描儀硬件控制模塊、徕卡TruView以及Cyclone PUBLISHER 軟件模塊。與本次發布的正射影象和放樣模塊一起，所有這些新增模塊擴展和加強了軟件的互用性。新發布的Cyclone 5.8軟件代表了高清晰測量領域主流軟件的技術發展方向。
“鑒於Cyclone5.8新發布的先進功能，無論是生產能力還是多用途性方面，該版軟件把三維激光掃描市場提升到了一個嶄新的水平上來。同時，對於那些期望進入高清晰測量領域（三維激光掃描領域）的組織或個人，該款軟件減小了他們學習激光掃描技術的難度，降低了他們進入激光掃描行業的門檻。借助我們的激光掃描工具集合，徕卡測量系統為您提供行業內最完整的解決方案。”徕卡測量系統掃描業務副總裁Ken Mooyman先生說。“新增的正射影像和放樣功能提升了徕卡測量系統做為行業領導的地位。新的HDS6000型相位激光掃描儀的結構緊湊，配以免費易用的浏覽量測軟件，HDS的工程應用獲得了更廣闊的市場空間。”
Cyclone5.8軟件將正射影像和數據量巨大的點雲數據整合到了CAD環境中，用戶可以此來生產各種改建圖紙和地形圖。
更多資源請請訪問：http://www.VeryCD.com/groups/langard/
引用  


²
 °² ° ²° 
  ° ° ° ²  ת 
²²²²      ת²°°²²²ת
ת ת±±² ²  ² 
°  °
 °  ° 
²²
²±±²
    
  
   ²
    ת² 
  ² ²
  ²
    ²±  ת
    ²
²  ²²°  
   
   ת
     
² ²²° ² ²² ²² ²
°°  ² °  °²  ² ² °°
 °² ² °   °² ² ²
    ² °² ² ²  
  °² ² ²°°°² ²
  °²²    zk.
² ²
   
 ²°
° ²°±²²°°²²
² ²°²°²
²²°²°²±°²
°²²°²
‏²±°°² °°°°°°°°°²
°²²²² ²°
 °°°²²²±²   ²
°²   ²²
²²  
²²² 
²² ²²
²°²²² ²²
²°²²² ²²
°° 
°°²²
²°²
ִ ִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִ ²² ִִִִִִִִִִִִִִִִִִִִִִִ ִ
°²²°°  °°²²°
ִ ִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִ ִ  ִִִִִִִִִִִִִִִִִִִִִִִִִִִ ִ
² ²
 ²²   [ MOST PROUDLY PRESENTS ]   ²² 
²² ²²
² ²
° °
Cyclone v7.0.2
Leica
Supplier . : RECOiL Size ..... : 23 x 5.00MB
Cracker .. : RECOiL Protection : FlexLM
Packager . : RECOiL Type ..... : Utility
Date ..... : 02-24-2009 OS ....... : Win
° °
² ²
²² ²²
° ²²²²     ²²²²° °
ִ ִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִ ִ
°²²° [ RELEASE NOTES ] °²²°
ִ ִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִ ִ
Cyclone lets users take advantage of traverse, back-sight, and
resection capabilities of the new Leica ScanStation laser scanner for
more cost-effective as-built and topographic surveys and lets users
create plant as-built models more efficiently from laser scans.
Unique, Efficient Foundation
The inherent completeness of 3D point clouds represents one of their
major advantages over other sources of geometric information. Cyclone's
unique Object Database Client/Server software architecture provides the
highest performance environment for laser scanning projects. Cyclone
software makes it easy for users to manage data efficiently in
databases. Users can work concurrently on databases, thereby reducing
the need to copy and/or transmit large point cloud project files.
Cyclone Modules for Flexible Configuration
Leica Cyclone is comprised of individual software modules for
different needs and for flexible product customization.
Cyclone-SCAN
Cyclone-SCAN is the software interface for operating the Leica
ScanStation, HDS6000, and HDS3000. User-specified scan area and density,
data filtering, scan scripting, and automatic recognition and extraction
of both planar and spherical Leica Geosystems HDS targets – all
contribute to this easy-to-use, intelligent data capture application.
Cyclone-REGISTER
Cyclone-REGISTER provides the complete set of tools for aligning point
clouds captured from different scanning positions, quickly and
accurately. Cyclone-REGISTER supports the use of Leica Geosystems HDS
targets to geo-reference scan data, as well as the ability to align
overlapping areas of point clouds – without the use of targets. This
results in optimum registration, and provides significant time- and
cost-savings by reducing the need to place and extract targets.
Cyclone-MODEL
This versatile, powerful module enables professionals to use point
clouds directly, to process them into objects for robust export into CAD
(and other applications), and to allow robust import of data from CAD
(and other applications). Cyclone-MODEL has the industry’s largest,
most complete and automated set of tools for accurately modeling 3D
point clouds as CAD geometry or as meshes for engineering, surveying,
construction, architectural and related applications.
Cyclone-SURVEY
Cyclone-SURVEY lets surveyors quickly extract relevant feature and
coordinate information from the point cloud data via the Cyclone Virtual
Surveyor function. Powerful tools support complex topographic models,
with intelligent mesh decimation that minimizes file size while
retaining accurate geometry. Cyclone-SURVEY is a subset of the
Cyclone-MODEL product and is an ideal module for surveyors.
Cyclone-VIEWER
Cyclone-VIEWER is a view-only version of the Cyclone software. This
product, free of charge, enables visualization of Cyclone data on a
desktop or portable PC, without a full featured Cyclone license. Share
your Cyclone databases with non-Cyclone-MODEL users; the Cyclone-VIEWER
provides full viewing capabilities to allow users to rotate, zoom and
navigate through Cyclone data, including point clouds and 3D models.
Cyclone-SERVER
Cyclone-SERVER enables individual members of workgroups to
simultaneously access 3D point cloud data sets and/or models. This
provides a powerful environment for collaborative design on large,
complex projects, and can significantly reduce project execution time.
Cyclone- SERVER supports the simultaneous connection of one through ten
client users to the same data server in a network environment. These
clients can be licensees of Cyclone-REGISTER, MODEL, SURVEY, VIEWER, or
Cyclone CloudWorx for AutoCAD and for MicroStation.
Leica TruView and Cyclone Publisher
Leica Cyclone PUBLISHER publishes point cloud data for web-based sharing
and viewing allowing access from anywhere in the world. Using the FREE
Leica TruView panoramic point cloud viewer, users can view, zoom in, or
pan over point clouds naturally and
intuitively.
ִ ִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִ ִ
°²²° [ INSTALLATION ] °²²°
ִ ִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִ ִ
Unzip, Unrar, Install. Use the patch.
ִ ִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִ ִ
°²²° [ GROUP iNFO ] °²²°
ִ ִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִ ִ
We are not taking any applications. We are an invite only group.
ִ ִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִ ִ
°²²° [ GREETINGS ] °²²°
ִ ִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִ ִ
Our friends, our loyal members and our fair competitors.
You know who you are.
ִ ִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִ ִ
°²²° [ RECOiL IN 2010 - ONE MORE IMPACT! ] °²²°
ִ ִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִִ ִ
[介紹及截圖摘自互聯網，未經過安裝測試，後果使用者自負]
共享服務時間:每天不定時
共享服務器:隨機
軟件版權歸原作者及原軟件公司所有，如果你喜歡，請購買正版軟件！
