資料介紹

VLAERO +是一個平面渦格法的亞音速和超音速飛機的氣動分析配置。有可視化的圖形用戶界面 ，直觀的工具欄提供幾何創建和編輯功能。 VLAERO +非常適合，它可以用來快速生產負荷，穩定性和控制數據的初步設計環境。數以千計的計算表明， VLAERO +不僅非常簡單的使用，也是高度精確的控制方程。

從圖形界面提供的功能包括：
快速直觀地訪問文件和可視化功能和非對稱模型的工具欄。
顯示窗口的快速可視化的幾何形狀，機翼和襟翼。
幾何數據編輯器允許添加，刪除，排序模型組件。
平移，縮放，伸展組件的組件操作。
控制界面編輯器，可以控制表面的圖形規范。
使用標准的機翼設計數據快速生成/修改幾何模型。
高級功能包括粘性修正計算器，地面效應模型生成器，批量處理。





















VLAERO+ is a planar vortex lattice method for the aerodynamic analysis of subsonic and supersonic aircraft configurations. With it's own GUI, VLAERO+ is ideally suited for the preliminary design environment where it can be used to quickly produce loads, stability and control data. Thousands of calculations have demonstrated that VLAERO+ is not only extremely simple to use but is also highly accurate within the limitations of the governing equations.

Geometry is represented by a series of trapezoidal patches . Camber and twist (including airfoil sections, wing twist, and control surface deflections) are easily specified using common aerodynamic design parameters. Output data are clearly tabulated, including interpolated geometry, surface pressures, force and moment coefficients, and distributed loads.
VLAERO+ includes a graphical user interface for geometry creation, program execution, and solution visualization. Intuitive toolbars provide geometry creation and editing functions. Component ordering and input file creation are performed transparently without the need to edit fixed format text files. Airfoil data management and specification are greatly simplified. Execution of the flow solver is controlled by the interface, and the results are processed for visualization.


System Requirements


This software is available for the following systems: Windows 2000/XP
