資料介紹

• Maya教程/視頻教程
• 計算機資料
• 3D處理軟件工具

[操作系統]:Windows 7 64bit
[已通過安全檢測]卡巴斯基KIS 11.0.1.400
[病毒庫發布日期]2011-02-26 00:37:00
共享服務時間:不定時
共享服務器:隨機

軟件版權歸原作者及原軟件公司所有，如果你喜歡，請購買正版軟件


壓縮包校驗:

AdvancedSkeleton_v1.85.For.Autodesk.Maya.ByB.G.7z　　　[CRC32:27A62BD8]

AdvancedSkeleton_v2.0.For.Autodesk.Maya.ByB.G.7z　　　[CRC32:21DCE08E]

AdvancedSkeleton_v3.0.For.Autodesk.Maya.ByB.G.7z　　　[CRC32:E8E3804A]

AdvancedSkeleton_v1.85_2.0_3.0.For.Autodesk.Maya.ByB.G.7z　　　[CRC32:4D7E9931]

AdvancedSkeleton_v3.1.For.Autodesk.Maya.ByB.G.7z　　　[CRC32:E52FCB7C]

AdvancedSkeleton_v3.5.For.Autodesk.Maya.ByB.G.7z　　　[CRC32:4EDF84A0]

AdvancedSkeleton_v3.1_3.5.For.Autodesk.Maya.ByB.G.7z　　　[CRC32:381EF3F7]

AdvancedSkeleton_v3.6.For.Autodesk.Maya.ByB.G.7z　　　[CRC32:B3D3CCD2]

AdvancedSkeleton_v3.6.1.For.Autodesk.Maya.ByB.G.7z　　　[CRC32:761A95CE]

AdvancedSkeleton_v3.7.For.Autodesk.Maya.ByB.G.7z　　　[CRC32:341E194D]


PDF教程校驗:


AdvancedSkeleton_v1.85使用初步hxsd.pdf　　　[CRC32:6B39BFD2]

AdvancedSkeleton_v2.0詳細教程5ds.pdf　　　[CRC32:B89F5677]

AdvancedSkeleton_v3.0使用講解起點CG.pdf　　　[CRC32:CA3CFEBE]






軟件介紹:



http://www.creativecrash.com/system/photos/000/010/285/10285/big/screen1.jpg?1251118603


http://www.creativecrash.com/system/photos/000/010/286/10286/big/lg_overview.jpg?1251118604


AdvancedSkeleton是Maya的角色設計的工具的合集。


主要特點是：

1.不再局限於預先設計好的FitSkeleton，而是可以創建任意的FitSkeleton；

2.具有本地旋轉軸和旋轉度，並可控；

3.可以從AdvancedSkeleton 回到 FitSkeleton，方便你做些改變然後重建AdvancedSkeleton；

4.AdvancedSkeleton在身體配置方面不再做限制，三個頭，五條腿，100個手指都可以；

5.支持拖拽“Selector Designer"等

官方簡介:


1. Introduction: AdvancedSkeleton is a collection of Maya tools for doing character setup. The Main Features of AdvancedSkeleton are: Not limited to a pre made FitSkeleton, you can create any FitSkeleton you like. The local rotation axis and rotation orders are set by the FitSkeleton, so you can control these. You can go back from AdvancedSkeleton to the FitSkeleton, and make changes and then rebuild the AdvancedSkeleton. Unlimited body configurations, 3 heads, 5 legs, 100 fingers, & anything goes. Comes with a drag`n`drop `SelectorDesigner`, that lets you easily create custom `Selector` user interfaces. And a `PoserDesigner`, that creates UIs for storing and retrieving poses.

1.簡介：AdvancedSkeleton是對Maya工具集合做角色設定.AdvancedSkeleton主要特點是：不僅限於預先作出FitSkeleton，您可以創建任意FitSkeleton.本地的旋轉軸和旋轉的都是由FitSkeleton，你就可以控制這些.你可以從AdvancedSkeleton回到FitSkeleton，並進行適當修改，然後重建AdvancedSkeleton.無限體配置，3頭，5腿，100的手指，什麼事情都能發生。拖拽`ñ`SelectorDesigner`，讓你輕松地創建自定義的`選擇用戶界面`和`PoserDesigner`，創建用於存儲和檢索用戶界面構成。

2. Installation:
Run the SETUP file (setup.exe) Choose the Destination Folder NOTE: destination folder must be your Maya user directory e.g.: C:/Documents and Settings/Name/My Documents/Maya/2008/ Finish installation. Start Maya. Now you will find a new Shelf called 'advancedSkeleton`

2.安裝：
運行SETUP文件（Setup.exe）選擇目標文件夾注意：目標文件夾必須是您的Maya用戶目錄例如：C：/ Documents and Settings /用戶名/ My Documents /maya/ 2008 /完成安裝。運行Maya.現在，你會發現一個新的工具欄'advancedSkeleton`


3. Overview: The key functionality of AdvancedSkeleton is to: Generate a complex motion system (AdvancedSkeleton) from a simple joint chain (FitSkeleton)

Joints that are on the `negative X` side of origin, gets read as the characters right side,
and will mirror these to the left side. The following information gets read from the FitSkeleton joints: names, positions, rotations, rotation axis, rotation orders. It also reads the following from the joints to determine the high level controls: labels and dependencyGraph input/output connections. The following joint labels will create high level controls:

FitSkeleton joint labels:
AdvancedSkeleton high level controls:
"Hand" & "Shoulder" Arm IK
"Hip" & "Foot" Leg IK
"LegAim" 3 bone (dog leg) IK
"Heel", "Ball" & "Toe" FootRoll system
"BigToe" & "PinkyToe" Foot rock-side-to-side system
"Root" & "Chest" (optional:"Mid") Spine IK
"Eye" Look at.. aim system
"0", "1", "2", etc.. Spline IK. (for tails, trunk, ponytails, etc.)
"Prop" Props that can be translated. (for hats, glasses, etc.)
FitTools also let you add the following attributes to the FitSkeleton: "TwistJoints" : will generate joints for distributing twist rotation along a bone. "Global" : will generate a control for maintaining world space orientation. "FreeOrient" : will preserve joints orientation, instead of auto orienting to X down. dependencyGraph input/output connections: AdvancedSkeleton will attempt to read any input/output connections from the FitSkeleton, and recreates the setup on both left & right side on the AdvancedSkeleton. See a example of this by loading the "biped" FitSkeleton template, and select the "Wrist" joint. Note that there are several custom attributes for controlling the fingers. This is a simple set-driven-keys setup, and it gets analyzed by AdvancedSkeleton, and implemeted in the full rig. You can create your own custom attributes to control any parts of the FitSkeleton. And it is not limited to setDrivenKey, but virtually any nodes connected in any way.

"3.概述：在AdvancedSkeleton主要功能是：從一個簡單的生成聯合鏈（FitSkeleton一個復雜的運動系統（AdvancedSkeleton））"

4. The Tools:


FitTools Browse through available FitSkeleton, and import any of them to the scene. You can add a your FitSkeleton to the list of available FitSkeletons, by saving it to the installDir/FitSkeletons/ folder. FitTools also has buttons for adding or removing FitSkeleton attributes and labels.

AdvancedSkeleton Builds the AdvancedSkeleton from selected joint hierarchy. Select the top joint of the FitSkeleton before executing this.

Utilities Utilities has following tools: Rebuild: :The FitSkeleton is always kept with the AdvancedSkeleton, allowing for joint placement tweaks at any time. To expose the original FitSkeleton, click "Toggle Fit/Advanced". This will display the FitSkeleton, which allows you to tweak the original joint placement. Run "Rebuild Skeleton" after you made tweaks to the FitSkeleton. Any objects that have been parented to the skeleton, will be re-parented to the newly built skeleton. And by turning on the "Rebuild Connections" option, AdvancedSkeleton will also re-link hypergraph connections.(e.g skinning) Skinning: Go to Build Pose: applies all the values stored when the AdvancedSkeleton was first build. Select DeformJoints: selects the joints intended for binding (skinning). This can also be done by selecting all members of the "DeformSet" Hide / UnHide MotionSystem: Allows you to display ONLY the joints intended for binding. Useful when using `edit membership` or `paint weights` tools. Locking: Assigns joints to a layer called "jointLayer", and sets the layers displayType to "Reference", This is useful so animators do not accidentally select and manipulate the joints. Boxes: Create/Remove/Mirror Poly-Boxes to fit the character. These boxes can be used as low-res geometry representation of your character, or use the Boolean function to create a more accurate low-res representation. The Bevel function, creates rounded corners for all the boolean objects. Cylinders: Creates nurbs cylinders which provides a alternativ way for selecting the controls. The FK control cylinders are by default transparent, so that the geometry appear to be the controls. Character Set: 'CreateCharacter' :Brings together all the essential attributes of the skeleton and creates a `character set node`, for Maya's non-linear animation tools. KillCharacter': Bakes all clips on selected character and restores keys to original nodes. Control Curves: Mirrors the shape of the control curves from left to right or vice versa After you created the AdvancedSkeleton, you might find that the control curves. are not ideally scaled/positioned for easy selecting. So you might have to sculpt the curves (by moving/scaling the cv`s) to fit better. This mirror tool allows you to do the adjustments on one side, then mirror it across. Partial Joints: creates child joints in the deformationSystem that rotates partially to its parent, Skinning to these joints provides partial rotation effect without the loss of volume that occurs when blending weights. FitMode: Preserves X-down joint orientations, and maintains set driven keys. This allows you to move joints, without loosing it`s X down alignment. Also lets you rotate finger joints, and preserve the `curl` set driven keys. Display: Joint size: Set the joint display size.

SelectorDesigner This tool is for creating `Selection Tools`. When you first open this, it will be blank.
First step is to bring in an image of your character as the background (Edit->Background..)
Next you need to create the buttons. To create a button: 1.Select the animation control object that you want the button to select when clicked. (e.g. "FKWrist_R") 2.Use the middle mouse button to `click and drag` the area you want the button.
Finally make sure to save the newly created tool. (File->Save) Once saved, you can add a shelf button that will launch the tool (File->;Put on shelf) See animated gif for how to use create buttons, and access the popup menus. These `Selection Tools` that are built by the `SelectorDesigner`, are free to be distributed. AdvancedSkeleton is not required to run these. A example `Selector` called "biped" is provided, click the last button on the shelf to run it. This is what the "biped" selector looks like:
Selector Tools comes with animation utilities menus.

PoserDesignerThis tool is for creating `Poser Tools`. When you first open this, it will be blank.
Along the toolbar of the window are the following controls:
By using these controls, you can build up your poser library:
Finally make sure to save the newly created tool. (File->Save) And like SelectorDesigner, you can add a shelf button that will launch the tool (File->;Put on shelf) `Poser Tools` built by `PoserDesigner` are also free for distribution, and does not require AdvancedSkeleton. Note that if you use the `only selected` option, then not only does the selected controls alone get stored, but it also looks for selected attributes in the channelBox. If you select 1 object and 1 attribute, and the attribute is of the `Limited Range` type attribute, then a slider will be generated to control the attribute (useful for blendShape attributes). The "anim" checkBox allows you to store animation clips instead of poses. Applying poses/animations: To apply pose/animation to your character simply click a button. To select or key the controls that are part of the pose/animation, right>click>.. a button. To apply pose/animation at the characters current position shift>click a button. To apply animation relative to current time shift>click a button. To apply animation relative to current values ctrl>click a button. Poser Tools comes with animation utilities menus.
Help Open the help files in a browser.

Selector:biped This is a sample `Selector`, created with the SelectorDesigner tool.

"4.工具介紹:"


5. Animation Utilities: Tools created by SelectorDesigner or PoserDesigner comes with a standard set of menu items, providing useful utilities for the animator.



-Edit>Refresh: Rescan the scene, and update the character drop down menu.
-Pose>Copy: Copy current pose. Ctrl/Alt>click will copy selected controls only. >;Paste: Paste pose. Ctrl/ Alt>click keeps the All control in the same place. >Reset: Go to Build Pose >Mirror: Mirror Pose. Use optionBox to specify side, space & axis. -Anim>Copy: Copy animation. Ctrl>click will copy selected controls only. >;Paste: Paste animation. Alt>click pastes "relative to current time" Ctrl>click pastes "relative to current time & values"

"5.動畫工具：由SelectorDesigner或PoserDesigner創建工具附帶了一個菜單項規定的標准，為動畫師有用的實用工具。"


6. The Controls:
FKIKControlCurves For every IK system there is a FKIKControlCurve. These are the controls that let you blend between FK / IK modes,
The attributes for these control curves are: FKIKBlend: value 0 = FK and value 10 = IK.
FKVis: value On = FK-Control-Curves visible
IKVis: value On = IK-Control-Curves visible
The FKVis / IKVis attributes are used for changing / animating the visibility of FK- / IK- Control-Curves. Useful for displaying only the ControlCurves needed for the mode you are working in.
FKCurves The FKCurves are light-blue circles.
These controls can only be rotated. The following attributes might be found on this type of control: global: for maintaining world space orientation.


IKCurves
The IKCurves are red boxes.
IKCurve can be translated and rotated (PoleVectorCurves can only be translated). The following attributes might be found on this type of control: swivel: sets the orientation of the knee follow: for switching whether to inherit parent transform or not. roll: foot rolling from heel to toe. rollAngle: the number of degrees to `roll` each transform in the foot roll system stiff: sharpness of splineIk curvature. stretchy: for blending in/out IK stretching. antiPop: set amount of scale compensating to avoid IK popping. See animated gif for example of antiPop.

IKCurves(foot-roll) Controls for manual rolling of heel and toe.
WagCurves Controls the automatic `wagging` function. The best way to understand this feature is to animate the rotation and see the effect. The added attributes are: use: turn this `on` to enable the calculation of the wag. timeOffset: number of frames to delay animation for each joint in the chain. multiply: rotation amount multiplier for every joint in the chain. increment: amount of increment of rotation for each joint in the chain towards the last joint.

PropCurves The PropCurve is similar to the FKCurve, except that the PropCurve can be translated.

AimCurves This controls the `Look At` aim system. Most used for eyes, were this control is the target that the eyes look at. The added attributes are: cross: Amount of cross eyed. Default is 1, where the eyes will be looking straight forward (empty stare) Set the value to 0, where the eyes will be converging to focus on the AimCurve control. follow: for switching whether to inherit parent transform or not.

CenterCurves This controls the top of the AdvancedSkeleton FK hierarchy. The following attributes might be found on this type of control: CenterBtwFeet: Set whether the center of the character should automatically be kept between the IK feet. Extra All the animation controls have a "Extra" control. These a accessed by selecting a curve, then pick-walk up (up-arrow). The `Extra-Controls` can be useful for many situations, such as avoiding gimbal lock. The shapes and colors of these control curves can be changed, by modifying the file: "asCurveIcons.ma".

6.控制：
FKIKControlCurves的IK系統有一個FKIKControlCurve。這是控制，讓你混合在一起FK/IK模式，
這些控制曲線的屬性：FKIKBlend：值0 = FK和值10 =IK。

7. Feedback: AdvancedSkeleton is constantly improving with input from the users. If you have any suggestions/comments about AdvancedSkeleton, please do not hesitate to contact us. [email protected] Copyright 2009 'Animation Studios'

"7.反饋:"





操作日志

---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
2009.12.24
===============================================================================
3.0是今天凌晨剛剛到手..嘻嘻...
本人測試安裝.. 確實可用..
改善了一些蹩腳的功能.. .
希望大家能用的上..


習慣使用1.85或者2.0版本的人也可以在這裡找到這些.. .

第一次發帖..
格式可能不是很標准..
還請大家多多包含.. .

也借此機會.
回報那些無私分享資源的人們.
.
謝謝你們.
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
2010.01.06
===============================================================================
大概是家裡速度慢的關系.. 我盡量24小時開機.. .

另外補充一個1.85+2.0+3.0的集合壓縮包.
因為收到過好多反饋..貌似1.85和2.0資源少的很抽象.. .
希望大家多多分流.

如果很急用的話..可以把郵箱留下.. .
^^.
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
2010.06.30
===============================================================================
更新了3.1版本.. 作者介紹.. 可以兼容Maya2010和2011.. 不過貌似有Bug報2011運行出錯的.. 2011版本的還是慎用吧.. 嘿嘿... .
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
2010.09.15
===============================================================================
更新3.5版本
官方更新日期:2010.08.24
支持系統:linux, mac, windows
軟件版本:6.x, 7.x, 8.x, 2008, 2009, 2010

至於2011..., 還是謹慎吧.., 版本裡並沒有寫2011..,

不過生命在於嘗試 (ps: ^^.., 雖然我沒試過..,)
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
2010.11.27
===============================================================================
更新3.6版本
Created / Updated:Sep 26, 2000 / Oct 22, 2010
Platforms:linux, mac, windows
Maya:6.x, 7.x, 8.x, 2008, 2009, 2010
(官方依然沒寫支持2011..不過看評論有2011用3.5咯..,應該3.6也ok.)

順帶從別的論壇摘抄的1.85,2.0,3.0教程.
(基本都是人家原創,.大家參考一下就好,支持人家勞動成果還是必要的.所以被我整成了不可編輯的PDF..)

更新1.85版本的鏈接.
(據說之前1.85已經成死鏈了..)
教程有針對1.85.所以更新一下
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
2011.01.19
===============================================================================
3.6.1版本修正了一些3.6版本的FKIK的Bug,增強了對Maya2011支持.
工作有些忙,剛閒下來更新.
大家見諒.
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
2011.02.26
===============================================================================

更新3.7版本.但是工作有些忙.就不做安裝測試了.
希望大家體諒.

---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
===============================================================================
